Sizing Chart
Product Specification
Frame
SmartForm C3 Alloy, SAVE, 1-1/8" headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA-73
Fork
SR Suntour XCT, 100mm, hydraulic lockout, Coil, 42mm offset (27.5") 46mm offset (29")
Rims
WTB SX19, 32h
Hubs
(F) Shimano HBTX 505 / (R) Shimano FHTX505
Spokes
Stainless Steel, 14g
Tires
WTB Ranger Comp, 27.5/29 x 2.25", DNA Compound
Pedals
Cannondale Platform
Crank
Prowheel, 36/22
Bottom Bracket
Cartridge, square taper
Chain
KMC X8, 8-speed
Rear Cogs
Sunrace, 11-34, 8-speed
Front Derailleur
Shimano Altus, 34.9 clamp
Rear Derailleur
Shimano Acera
Shifters
Shimano M315 Rapidfire Plus, 8-speed
Handlebar
Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm
Grips
Cannondale Dual-Density
Stem 6061 Alloy, 31.8, 7°
Headset
Semi Integrated, 1-1/8"
Brakes
Shimano MT200 hydraulic disc, 160/160mm RT10 rotors
Saddle
Cannondale Stage 3
Seatpost
Cannondale 3, 6061 Alloy, 31.6 x 350/400mm
Sizes
XS, SM, MD, LG, XL
