Crankset
Stout 2x, forged alloy
Bottom Bracket
Square-tapered, 73mm, internal bearings, 122.5mm spindle
Shift Levers
microSHIFT, TS39-8R, 2x8-speed
Cassette
SunRace, 8-speed, 11-34t
Rear Derailleur
microSHIFT Mezzo 8-speed
Chain
KMC X8 EPT, anti-rust coating, 8-speed w/ reusable Missing Link™
Front Derailleur
microSHIFT Marvo 2x8
Spokes
Stainless, 14g
Front Tire
Ground Control Sport, 29x2.3"
Rear Hub
Formula SP-2125, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
Inner Tubes
Schrader, 40mm valve
Front Hub
Formula 6-Bolt, disc, 100x9mm spacing, quick-release, 32H
Rims
Specialized alloy, disc only, double-wall, 25mm inner width, 32h
Rear Tire
Ground Control Sport, 29x2.3"
Seat Binder
Alloy, quick release, 34.9
Frame
Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
Front Brake
Radius CX7, mechanical disc, 160mm
Rear Brake
Radius CX7, mechanical disc, 160mm
SeatPost
Alloy, 2-bolt clamp, 30.9mm
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Grips
Specialized Trail Grips, lock-on
Saddle
Bridge Sport, steel rails
Handlebars
Specialized, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Pedals
SBC-54 Flat pedal
Fork
SR Suntour XCE 29, 28mm stanchions, Rx Tune, coil spring, QR, 90/100mm travel (size-specific), 46mm offset
* Specifications are subject to change
S | M | L | XL | XXL | |
---|---|---|---|---|---|
Crank Length | 170mm | 170mm | 175mm | 175mm | 175mm |
Handlebar Width | 720mm | 740mm | 740mm | 740mm | 740mm |
Stem Length | 45mm | 60mm | 60mm | 70mm | 70mm |
Saddle Width | 155mm | 143mm | 143mm | 143mm | 143mm |
Seatpost Length | 350mm | 400mm | 400mm | 400mm | 400mm |
Stack | 607mm | 616mm | 626mm | 640mm | 654mm |
Reach | 405mm | 425mm | 445mm | 465mm | 485mm |
Head-Tube Length | 95mm | 95mm | 105mm | 120mm | 135mm |
Head-Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° | 68.5° |
B-B Height | 310mm | 310mm | 310mm | 310mm | 310mm |
B-B Drop | 62mm | 62mm | 62mm | 62mm | 62mm |
Trail | 97mm | 97mm | 97mm | 97mm | 97mm |
Fork Length (full) | 505mm | 515mm | 515mm | 515mm | 515mm |
Fork Rake/Offset | 46mm | 46mm | 46mm | 46mm | 46mm |
Front-Center | 672mm | 696mm | 719mm | 745mm | 770mm |
Chain-Stay Length | 440mm | 440mm | 440mm | 440mm | 440mm |
Wheelbase | 1105mm | 1128mm | 1152mm | 1178mm | 1203mm |
Top-Tube Length (horizontal) | 586mm | 608mm | 630mm | 654mm | 679mm |
Bike Stand-Over Height | 732mm | 754mm | 781mm | 820mm | 853mm |
Seat-Tube Length | 360mm | 400mm | 450mm | 500mm | 560mm |
Seat-Tube Angle | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
