  • Scott Scott Spark 970
  • Scott Scott Spark 970

Scott Scott Spark 970

$2,899.99
Excl. tax

The rating of this product is 0 out of 5

 (0)
Out of stock
  • Spark Alloy SL Frame
  • RockShox Judy 130mm Fork
  • X-Fusion Nude 5, 120mm, TwinLoc
  • SRAM NX-SX Eagle 12 Speed
  • Shimano Disc Brakes
  • Syncros X-30SE TR Rims
  • Schwalbe Wicked Will Tires
  • Syncros Dropper Post and Parts

FRAME

Spark Alloy SL 6011
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline

FORK

RockShox Judy Silver TK Solo Air
15x110mm QR axle / 42mm offset / Tapered Steerer
2-Modes / Reb. Adj. / Lockout / 130mm travel

REAR SHOCK

X-Fusion NUDE 5 RLX Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 120-80-Lockout / T165X45mm

REMOTE SYSTEM

SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes

REAR DERAILLEUR

SRAM NX Eagle 12 Speed

SHIFTERS

SRAM SX Eagle Trigger

CRANKSET

SRAM SX Eagle DUB
55mm CL / 32T

BB-SET

SRAM DUB PF 92 MTB Wide / shell 41x92mm

CHAIN

SRAM CN SX Eagle

CASSETTE

SRAM SX-PG1210 / 11-50 T

BRAKES

Shimano MT201 Disc

ROTOR

Shimano SM-RT10 CL / F&R 180mm

HANDLEBAR

Syncros Fraser 2.0 DC Alloy 6061 D.B.
mini Rise / back sweep 8° / 760mm
Syncros Pro lock-on grips

H'STEM

Syncros DC 3.0
Syncros Cable Integration System
0° rise / 6061 Alloy / 31.8mm / 1 1/8"

SEATPOST

Syncros Duncan Dropper Post 2.5
31.6mm / S & M size 130mm / L & XL size 150mm

SEAT

Syncros Tofino 2.5 Regular

HEADSET

Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB

HUB (FRONT)

Formula CL-811 / 15x110mm

HUB (REAR)

Formula CL-3248 / 12x148mm

SPOKES

Stainless Black 15G / 1.8mm

RIMS

Syncros X-30SE / 32H / 30mm

FRONT TIRE

Schwalbe Wicked Will 29x2.4"
Performance / TLR / Addix

REAR TIRE

Schwalbe Wicked Will 29x2.4"
Performance / TLR / Addix

APPROX WEIGHTS IN KG

14.95 (with tubes)

APPROX WEIGHTS IN LBS

32.96 (with tubes)

MAX. SYSTEM WEIGHT

128 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.


Geometry of SCOTT Spark 970 Bike orange
                S   M   L   XL
A HEAD TUBE ANGLE             65.8 °   65.8 °   65.8 °   65.8 °
B HEAD TUBE LENGTH             90.0 MM 90.0 MM 105.0 MM 115.0 MM
C TOP TUBE HORIZONTAL             561.0 MM 589.0 MM 613.0 MM 641.0 MM
D STANDOVER HEIGHT             759.0 MM 767.0 MM 778.0 MM 801.0 MM
E BB OFFSET             -43.5 MM -43.5 MM -43.5 MM -43.5 MM
F BB HEIGHT             331.5 MM 331.5 MM 331.5 MM 331.5 MM
G WHEEL BASE             1,145.0 MM 1,174.0 MM 1,205.0 MM 1,236.0 MM
H BB CENTER TO TOPTUBE CENTER
I BB CENTER TO TOP OF SEATTUBE             415.0 MM 440.0 MM 490.0 MM 540.0 MM
J SEAT ANGLE             75.7 °   75.9 °   76.4 °   76.7 °
K CHAINSTAY             437.5 MM 437.5 MM 437.5 MM 437.5 MM
L REACH             410.0 MM 440.0 MM 470.0 MM 500.0 MM
M STACK             607.5 MM 607.5 MM 617.7 MM 627.0 MM
N STEM LENGTH             50.0 MM 60.0 MM 60.0 MM 70.0 MM
0 TRAIL             107.0 MM 107.0 MM 107.0 MM 107.0 MM
P FORK LENGTH             540.0 MM 540.0 MM 540.0 MM 540.0 MM
Q MAXIMUM SEATPOST INSERTION             150.0 MM 175.0 MM 225.0 MM 275.0 MM
R CRANK LENGTH             170.0 MM 175.0 MM 175.0 MM 175.0 MM
