KEY FEATURES

• Aspect 700/900 Alloy Frame
• Suntour XCR32/X1-LO-R 100mm Fork
• Shimano Alivio 18 Speed
• Shimano Brakes
• Kenda Booster

Bike Specs:

• FRAME

  Aspect 900-700 series / Alloy 6061 Custom Butted Tubing
  BSA73 / Internal Cable Routing / replaceable hanger

• FORK

  Suntour XCR32/X1-RL-R / Hyd. Lockout / Reb. Adj.
  100mm travel

• REAR DERAILLEUR

  Shimano Alivio RD-M3100
  18 Speed

• FRONT DERAILLEUR

  Shimano FD-M3120 Side Swing / 31.8mm

• SHIFTERS

  Shimano SL-M3100
  R-fire plus / 2 way release
  w/gear indicator

• CRANKSET

  Shimano FC-MT2102
  2-piece Design / 36X22

• BB-SET

  Shimano BB-MT500
  Hollowtech II / threaded

• CHAIN

  KMC X9

• CASSETTE

  Shimano CS-HG200-9 / 11-36T

• BRAKES

  Shimano MT200 / Hydr. Disc

• ROTOR

  Shimano SM-RT10 CL rotor / F&R 160mm

• HANDLEBAR

  Syncros 3.0 / 720mm
  black / 31.8mm / 12mm rise / 9° BS
  Syncros Pro Grip

• H'STEM

  Syncros 3.0 / 7° / Black

• SEATPOST

  Syncros 3.0
  31.6mm / 350mm / Black

• SEAT

  Syncros 3.0

• HEADSET

  Syncros OE Press Fit / 1 1/8"
  OD 50mm / ID 44mm

• HUB (FRONT)

  Shimano HB TX505

• HUB (REAR)

  Shimano FH-TX5058

• SPOKES

  14 G / stainless / black

• RIMS

  Syncros X-20 Disc
  32H / black

• FRONT TIRE

  Kenda Booster
  2.4" / 30TPI

• REAR TIRE

  Kenda Booster
  2.4" / 30TPI

• PEDALS

  VP VP-536

• APPROX WEIGHTS IN KG

  14.15

• APPROX WEIGHTS IN LBS

  31.20

• MAX. SYSTEM WEIGHT

  128 kg
  The overall weight includes the bike, the rider, the equipment, and possible additional luggage.

Geometry Specs:
